Compact AC Servo Motor
Characteristics:
★ Small/Middle/High Inertia
★ Embedded Magnet Rotor
★ High power density with   smaller size
★ Powerful overload capacity
★ High efficiency and low   fever
★ Low ripple torque

Application   Fields:
★ Robot Industry
★ Machine tool feed system
★ Textile machinery
★ Packaging machinery
★ Medical equipment
★ Food machinery
★ Automatic production lines
★ Intelligent storage   equipment
★ Logistics sorting system
★ Gate equipment
★ Mobile AGV
★ Semiconduct industry   equipments
★ Lithium battery equipment
★ Special automatic machinery


  • Frame Size 040
  • Frame Size 060
  • Frame Size 080
  • Frame Size 130
  • Frame Size 180





Model
Voltage
Rated output
Rated Torque
Rated speed
Peak speed
Rated current
Peak torque
Peak current
Poles
Rotor inertia
Torque constant
Voltage constant

U
Pn
Mn
Nn
Nn
In
Mm
Im
　
Jm
Kt
Ke

　
W
Nm
rpm
rpm
A
Nm
A
Pair
kgcm2
Nm/A
V/Krpm
QC040A01030K¨-10¨¨¨
220VAC
100
0.31
3000
5000
1.15
1.1
4.2
5
0.074(0.08)
0.326
19.7
QC040B01030K¨-10¨¨¨
380VAC
100
0.31
3000
5000
0.58
1.1
2.1
5
0.074 (0.08)
0.652
39.4





Motor Length L(mm)
L: Without brake
L: With brake
QC040A01030K¨-10¨¨¨
81.5
114.5
QC040B01030K¨-10¨¨¨
81.5
114.5
